MSI A320M-A PRO Motherboard Socket AM4 – M001

MSI
MSI

$38.00

Out of stock

Compare

Description

This is a motherboard only, without any accessories (driver disc, manual, cables, I/O shield, expansion cards etc. are not included)

Model Number A320M-A PRO
EAN 4719072663889
UPC 824142193891
BIOS 1 x 128 Mb flash
UEFI AMI BIOS
ACPI 6.1, SM BIOS 2.8
Multi-language
Chipset AMD A320
CPU Interface Socket AM4
CPU Support
Front Side Bus
RAM Technology DDR4 (Dual Channel)
RAM Slots 2 x 288-pin
RAM Speeds DDR4 1866
DDR4 2133
DDR4 2400
DDR4 2667 (O.C.)
DDR4 2933 (O.C.)
DDR4 3200 (O.C.)
Max. Memory Support 32GB
PCI Express 3.0 x16 1
PCI Express 2.0 x1 1
S-ATA III Port(s) 4
RAID Raid 0/1/10
LAN Speed 10/100/1000
On-Board LAN 1 x Realtek 8111H
On-Board Audio Realtek ALC892 Codec
On-Board Video AMD processor with integrated graphics is required
Back PS/2 Mouse Port 1
Back PS/2 Keyboard Port 1
Back USB 2.0 Port(s) 2
Back USB 3.2 Port(s) Type-A Gen 1 4
Back DVI-D Port(s) 1
Back HDMI Port(s) 1
Back Audio Jack(s) 3
24-pin ATX Power 1
4-pin ATX Power 1
USB 2.0 Header(s) 2
USB 3.2 Header(s) Gen 1 1
COM Port Header(s) 1
Front Panel Audio Connector 1
TPM Header(s) 1
Form Factor Micro ATX
Product Width 187mm
Product Length 226mm
Special Features Supports 1st, 2nd and 3rd Gen AMD Ryzen/Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4.
Supports DDR4 Memory, up to 3200 (OC) MHz.
Audio Boost: Reward your ears with studio grade sound quality.
DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
