This is a motherboard only, without any accessories (driver disc, manual, cables, I/O shield, expansion cards etc. are not included)
MSI B450M-A PRO MAX MOTHERBOARD AMD B450 SOCKET AM4 MICRO ATX
MSI B450M-A PRO MAX AMD SOCKET AM4 AMD ATHLON AMD RYZEN AMD RYZEN 3 2ND GENERATION AMD RYZEN 3 3RD GENERATION AMD RYZEN… SOCKET AM4 DDR4-SDRAM 32 GB
- Supports 1st 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzenwith Radeon Graphics / Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4
- Supports DDR4 Memory up to 4133 (OC) MHz
- Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
- Audio Boost: Reward your ears with studio grade sound quality
- X-Boost: Software that auto-detects and allows you to boost the performance of any storage or USB device
AMD AM4 motherboard inspired from architectural design with Core Boost DDR4 Boost Turbo M.2 USB 3.2 Gen1Supports 1st 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4Supports DDR4 Memory up to 4133 (OC) MHzTurbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.Audio Boost: Reward your ears with studio grade soun
Feature | Value |
---|---|
Brand | MSI |
Manufacturer Product Type | MSI Motherboards |
Product Type | Motherboards |
Product Family | B450M-A PRO MAX |
Collection Model | MSI B450M-A PRO MAX |
MPN | B450M-A PRO MAX |
HDD size | 2.5/3.5inch |
USB 2.0 ports quantity | 4 |
HDMI ports quantity | 1 |
Motherboard form factor | Micro ATX |
Number of memory slots | 2 |
Supported memory types | DDR4-SDRAM |
Processor socket | Socket AM4 |
Motherboard chipset family | AMD |
Number of mounting holes | 6 |
USB connector type | USB Type-A |
Drivers included | Y |
Harmonized System (HS) code | 84733020 |
Parallel connector | Y |
Parallel processing technology support | Not supported |
Quick installation guide | Y |
Serial port headers | 1 |
TPM connector | Y |
Power source type | ATX |
Width | 236 mm |
Headphone outputs | 1 |
Discrete graphics support | Y |
Memory channels | Dual |
Memory channels | Dual-channel |
Unbuffered memory | Y |
Chassis intrusion connector | Y |
Maximum internal memory | 32 GB |
Depth | 200 mm |
Supported memory module capacities | 4GB 8GB 16GB |
Supported memory module capacities | 4GB8GB16GB |
Maximum graphics adapter memory | 2048 MB |
Maximum graphics card memory | 2048 MB |
Supported memory clock speeds | 18662133240026672800293330003066320034663733386640004133 MHz |
CPU fan connector | Y |
ATX Power connector (24-pin) | Y |
Non-ECC | Y |
PCI Express x16 (Gen 3.x) slots | 1 |
ECC | Y |
PCI Express x16 slots | 1 |
Clear CMOS jumper | Y |
Microphone in | Y |
Supported storage drive types | HDDSSD |
Cooling type | Passive |
Windows operating systems supported | Windows 10 x64 Windows 7 x64 |
Windows operating systems supported | Windows 10 x64Windows 7 x64 |
Front panel connector | Y |
Front panel audio connector | Y |
DirectX version | 12.0 |
LAN controller | Realtek 8111H |
PCI Express x1 (Gen 2.x) slots | 1 |
Ethernet interface type | Gigabit Ethernet |
Memory slots type | DIMM |
Cables included | SATA |
Supported storage drive interfaces | M.2 Serial ATA III |
Supported storage drive interfaces | M.2Serial ATA III |
Supported storage drive interfaces | SATA III |
Supported storage drive interfaces | Serial ATA III |
Supported storage drive types | HDD & SSD |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Audio output channels | 7.1 channels |
Audio chip | Realtek ALC892 |
Supported processor sockets | Socket AM4 |
Maximum number of SMP processors | 1 |
PS/2 ports quantity | 2 |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 2.0 connectors | 2 |
DVI-D ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Supported storage drive types | HDD SSD |
Motherboard chipset | AMD B450 |
Maximum Resolution | 4096 x 2160 Pixels |
Ethernet LAN | Y |
Compatible processor series | AMD AAMD Athlon X4AMD Ryzen |
Wi-Fi | N |
Processor manufacturer | AMD |
Component for | PC |
B450M-A PRO MAX
AM4 B450 2 x 288 Pin DIMM Realtek 8111H Realtek ALC892 m-ATX HDMI DVI-D 4 x USB 3.2 Gen1 2 x USB 2.0
